3 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components (D6H) Axles
4 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components (M6V) Axles TRAILER AXLE SOLUTIONS Since 2005, we’ve been a leading axle supplier to the utility trailer parts and recreational vehicle industries. Our trailer axles are engineered and constructed with cutting-edge technology, making them among the best in terms of quality and durability. Our state-of-the-art robotic welders ensure the highest precision on every component you buy, leaving you with peace of mind on the road ahead. Plus, we make our replacement cargo axle assemblies and components traceable, giving us optimum product visibility and serviceability for your convenience. Benefits of Lippert Axles We utilize robotic welding for consistent, fully penetrated welds every time. Robotic Welding Aluminum alloy, upgraded Valcrum premium oil bath caps will not crack like plastic oil caps. Aluminum Alloy Valcrum Caps We offer standard electric, forward selfadjusting and hydraulic brakes for your replacement axle. Multiple Brake Options This system saves time, requiring no disassembly and filling the entire bearing cavity with grease, allowing for complete submersion. This system offers better long-term protection over standard hubs. Super Lube Lubrication System Powder-coated axle tube finish prevents premature corrosion from road salt and other chemicals. Durable Finish Our axles are QAI-certified to CSA Standard CAN3-D313-M85 for exceptional quality. Exceptional Quality Protected connections help prevent corrosion and ensure long-term performance. Waterproof Electrical Wiring Connections Each axle is magnet-amp checked for proper function in all wiring. Magnet-Amp Checked
5 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components (M6V) Axles Axle Specification Sheet
6 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Axles Feature Torsion Axles Spring Axles Warranty 11-year 6-year Axle configuration Single, tandem Single, tandem, triple Axle capacity 2K - 7K (diamond) / 2K - 12K (square) 2K - 16K Idler axles 2K - 8K 2K - 8K CSA certification 2K - 8K 2K - 8K Valcrum premium oil caps (included) 8K - 12K 8K - 16K Oil bath (option) 7K - 12K 7K - 16K Forward self-adjusting brakes (option) 3.5K - 12K 3.5K - 16K Hutch HD suspension system (option) -- 10K - 16K Super lube lubrication system (option) 2K - 8K 2K - 8K Diamond pattern torsion axle Square pattern torsion axle TORSION AXLES • Requires less maintenance than spring axles • Rubberized torsion beam and cords absorb road shock and vibrations for a quiet, smooth ride • Available in square and diamond orientations • Various starting angles control trailer height • Independent wheel suspension SPRING AXLES • Integrated, one-piece spindle flange • Straight or drop spindles • Slipper or double-eye leaf spring suspension • Standard or upgraded equalized suspension (M6V)
7 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Axles BUILD YOUR OWN AXLE Example Axle Number Axle Number Breakdown, Definitions & Options LCI60-SB-86.5-68.5-NOSP-OS-L-65517-7226-30PT In crafting our axle assemblies, we assign part numbers that delineate the characteristics of each component. These numbers correspond to the axle capacity, beam type, hub face dimension, spring center dimension, tie plate type, spring mounting type, lubrication type, bolt pattern, leaf spring type and pigtail type. The foundational structure of our part numbering system is outlined below. Model Code Description LCI20 2,000 lbs. LCI35 3,500 lbs. LCI44 4,400 lbs. LCI52 5,200 lbs. LCI60 6,000 lbs. LCI70 7,000 lbs. LCI80H (hybrid) 8,000 lbs. LCI80 8,000 lbs. LCI100S (short) 10,000 lbs. LCI120 12,000 lbs. LCI160 16,000 lbs. Hub Face Dimension Distance between wheel mounting surfaces of hubs Spindle and Brake Code Description Spindles S Straight spindle D 4" drop spindle Brakes B Electric drum brake BSA Electric drum brake, self-adjust I Idler hub, no brake HUSFB Hydraulic uni-servo drumbrake, free backing AB Air brake D Hydraulic disc brake Example Axle Number Breakdown & Definitions Model Spindle and Brake Hub Face Dimension Spring Center Dimension Tie Plate Spring Mounting Lubrication Hub or Hub / Drum Leaf Spring Pigtail Type LCI60 SB 86.5 68.5 NOSP OS L 65517 7226 30PT Pigtail Type Code Description 18PT 18" pigtails 30PT 30" pigtails Leaf Spring Industry number, see leaf springs table Hub or Hub / Drum Code Bolt Pattern 440 4 on 4" 545 5 on 4-1/2" 5475 5 on 4-3/4" 550 5 on 5" 555 5 on 5-1/2" 655 6 on 5-1/2" 660 6 on 6" 86517 8 on 6-1/2", 1/2" studs 86537 8 on 6-1/2", 9/16" studs 86580-9/16 8 on 6-1/2", 9/16" stud, 8K 86580-5/8 8 on 6-1/2", 5/8" stud, 8K 865 8 on 6-1/2", 5/8" studs, 10K - 12K 8/275 8 on 275 mm, 16K Spring Center Dimension Code Description NOSS No spring seats welded Distance between spring centers Tie Plate Code Description NOSP Standard tie plate FIXSS Fixed spring seats, both sides (10K - 16K) ADJSS One fixed and one adjustable spring seat (10K - 16K) HUTSS HD suspension system spring seat, welded (10K - 16K) Spring Mounting Code Description OS Overslung, on top of axle tube US Underslung, underneath axle tube Lubrication Code Description L Super-lube G Standard grease O Oil lubrication (M6V)
8 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts MAGNET KITS Retail Clamshell # Axle Capacity Fits Brake Size 2024120112 3,500 lbs. 10" x 2-1/4" 2024120113 5,200 - 7,000 lbs. 12" x 2" 2024120114 8,000 - 16,000 lbs. 12-1/4" 2024120112 2024120113 2024120114 ADJ. SCREW & SPRING KIT Retail Clamshell # Fits Brake Size Brake Adjustment 2024120111 10" and 12" Manual 2024120111 2024013263 Retail Box # Axle Capacity Bolt Pattern Stud Size 2025013495 2,200 lbs. 4 on 4" 1/2" 2025013496 2,200 lbs. 5 on 4-1/2" w/ 5-1/2" flange 1/2" 2025013497 2,200 lbs. 5 on 4-1/2" w/ 6-1/2" flange 1/2" 2024013263 3,500 lbs. 5 on 4-1/2" 1/2" 2024044866 3,500 lbs. 5 on 5" 1/2" 2025013498 4,400 lbs. 6 on 5-1/2" 1/2" IDLER HUB KITS Retail Box # Axle Capacity Brake Hub Size Bolt Pattern Stud Size 2024013264 3,500 lbs. 10" 5 on 4-1/2" 1/2" 2024114172 3,500 lbs. 10" 5 on 5-1/2" 1/2" 2024013262 6,000 lbs. 12" 6 on 5-1/2" 1/2" 2024013260 7,000 lbs. 12" 8 on 6-1/2" 1/2" 2024013261 7,000 lbs. 12" 8 on 6-1/2" 9/16" BRAKE HUB KITS BRAKE ASSEMBLIES Retail Box # Axle Capacity Brake Size Vehicle Side Manual Adjusting 297956 3,500 lbs. 10" x 2-1/4" Driver 298274 3,500 lbs. 10" x 2-1/4" Pass. 298275 5,200 - 8,000 lbs. hybrid 12" x 2" Driver 298276 5,200 - 8,000 lbs. hybrid 12" x 2" Pass. Self Adjusting 296649 3,500 lbs. 10" x 2-1/4" Driver 296650 3,500 lbs. 10" x 2-1/4" Pass. 296651 5,200 - 8,000 lbs. hybrid 12" x 2" Driver 296652 5,200 - 8,000 lbs. hybrid 12" x 2" Pass. 2024055286 8,000 lbs. 12-1/4" x 3-3/8" Driver 2024055287 8,000 lbs. 12-1/4" x 3-3/8" Pass. 2024055288 10,000 lbs. 12-1/4" x 3-3/8" Driver 2024055289 10,000 lbs. 12-1/4" x 3-3/8" Pass. 2024055290 12,000 - 16,000 lbs. 12-1/4" x 5" Driver 2024055291 12,000 - 16,000 lbs. 12-1/4" x 5" Pass. 2024055288 2024013264 (M6V) 296649
9 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) 2025027756 2025027757 2025027760 2025027755 2025027754 2025027758 SPINDLE WASHERS 10-Pack # Axle Capacity Style Inside Diameter Outside Diameter 2025027756 2,200 - 4,400 lbs. Round 1" 1-11/16" 2025027757 2,200 - 4,400 lbs. D-flat 1" 1-11/16" 2025027755 2,200 - 8,000 lbs. Locking tang 1" 1-11/16" 2025027760 5,200 - 8,000 lbs. D-flat 1-1/16" 2" 2025027754 5,200 - 8,000 lbs. Round 1-1/16" 2" 2025027758 10,000 lbs. Round 1-1/2" 3" 2025027759 12,000 - 16,000 lbs. Round 1-7/8" 3-3/8" COTTER PINS 10-Pack # Axle Capacity Diameter Length 2025027790 Up to 8,000 lbs. 1/8" 1-3/4" 2025027791 10,000 - 16,000 lbs. 1/4" 2-1/4" 2025027790 2025027791 GREASE ZERK 10-Pack # For 2025027802 Wet bolt equalizers and lubricated axles SPINDLE NUT KITS 2023134656 2023134657 2023134021 2023134022 10-Pack # Axle Capacity Thread Size 2025027769 3,500 - 8,000 lbs. 1"-14 2025027770 10,000 lbs. 1-1/2" - 12 2025027771 12,000 - 16,000 lbs. 1-3/4" - 12 SPINDLE NUTS 2025027770 2025027769 2025027771 Retail Clamshell # Axle Capacity Thread Size Includes 2023134656 2,200 - 4,400 lbs. 1"-14 Spindle nut, round washer, and cotter pin 2023134657 2,200 - 4,400 lbs. 1"-14 Spindle nut, D-flat washer, and tang washer 2025027380 5,200 - 8,000 lbs. 1"-14 Spindle nut, D-flat washer, and tang washer 2025027381 5,200 - 8,000 lbs. 1"-14 Spindle nut, round washer, and cotter pin 2023134021 10,000 lbs. 1-1/2" - 12 Spindle nut, round washer, and cotter pin 2023134022 12,000 - 16,000 lbs. 1-3/4" - 12 Spindle nut, round washer, and cotter pin
10 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) • High-quality tapered roller bearings • High-quality alloy blend reduces vibration • Includes outer bearing with cotter pin, outer race, inner race, inner bearing, and grease seal • Easy, DIY installation • Includes one bearing Retail Kit # Poly Bag Kit # Axle Capacity Note: Industry number is for reference only. Do not use this number to order your parts Seal # Outer Bearing Industry # Outer Race Industry # Inner Race Industry # Inner Bearing Industry # 2023133979 -- 2,200 lbs. L44649 L44610 L44610 L44649 139514 2023133980 333948 3,500 lbs. L44649 L44610 L68111 L68149 122087 2023133981 333949 5,200 lbs. LM67048 LM67010 25520 25580 122088 2023133982 333950 6,000 lbs. 15123 15245 25520 25580 122088 2023133983 333951 7,000 lbs. 14125A 14276 25520 25580 122088 2023133984 -- 8,000 lbs. 02475 02420 25520 25580 122088 2023133985 -- 10,000 lbs. 25580 25520 382A 387A 176692 2023133986 -- 12,000 - 16,000 lbs. 28622 28682 3920 3984 295924 Sleeve # Sleeve Qty Axle Capacity Inner Diameter Note: Industry number is for reference only. Do not use this number to order your parts Race Industry # Lippert OE # Industry # Outer 2025027336 9 2,200 - 3,500 lbs. 1.0625" 122089 L44649 L44610 2025027365 8 5,200 lbs. 1.2500" 122090 LM67048 LM67010 2025027366 7 6,000 lbs. 1.2500" 122091 15123 15245 2025027341 8 7,000 lbs. 1.2500" 127009 14125A 14276 2025027344 5 8,000 lbs. 1.2500" 129752 02475 02420 2025027342 5 10,000 lbs. 1.7500" 122066 25580 25520 2025027361 5 12,000 - 16,000 lbs. 2.2500" 293382 28682 28622 Inner 2025027336 9 2,200 lbs. 1.0625" 122089 L44649 L44610 2025027338 8 3,500 lbs. 1.3775" 122092 L68149 L68111 2025027342 5 5,200 - 8,000 lbs. 1.7500" 122066 25580 25520 2025027343 5 10,000 lbs. 2.2500" 183807 387A 382A 2025027360 4 12,000 - 16,000 lbs. 2.6250" 293380 3984 3920 Cotter pin Grease seal Inner bearing Outer bearing Inner race Outer race BEARING KITS & COMPONENTS BEARINGS 2023133982 2023133984 Universally compatible with Dexter
11 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) Retail Clamshell # Axle Capacity Spindle Shaft Diameter Grease Seals 2023134653 2,200 lbs. 1.5" 2023134654 3,500 lbs. 1.719" 2023134655 5,200 - 8,000 lbs. 2.25" Oil Seals 2023134018 5,200 - 8,000 lbs. 2.250" 2023134019 10,000 lbs. 2.875" 2023134020 12,000 - 16,000 lbs. 3.125" GREASE & OIL SEALS 2023134654 2023134018 BEARING KITS Retail # Axle Capacity Clamshell 2023133979 2,000 lbs. 2023133980 3,500 lbs. 2023133981 5,200 lbs. 2023133982 6,000 lbs. 2023133983 7,000 lbs. Retail Box 2023133984 8,000 lbs. 2023133985 10,000 lbs. 2023133986 12,000 - 16,000 lbs. 2023133979 Non Lubed Clamshell # Lubed Clamshell # Axle Capacity Bore Size Dust Caps 2023134658 2023134661 2,000 - 3,500 lbs. 2" 2023134659 2023134662 5,200 - 6,000 lbs. 2-1/2" 2023134660 2023134011 7,000 - 8,000 lbs. 2-3/4" Dust Cap Rubber Plug 2023134012 For use with standard lubed dust caps STANDARD DUST CAPS SPINDLE NUT KITS 2023134012 2023134661 2023134658 Retail Clamshell # Axle Capacity Washers Included 2023134656 2,000 - 8,000 lbs. 1" round 2023134657 2,000 - 8,000 lbs. 1" D-flat / 1" locking tang 2023134021 10,000 lbs. 1-1/2" round 2023134022 12,000 - 16,000 lbs. 1-7/8" round 2023134021
12 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts • Easy, DIY installation • Includes one race Sleeve # Sleeve Qty Axle Capacity Outer Diameter Note: Industry number is for reference only. Do not use this number to order your parts Bearing Industry # Lippert OE # Industry # Outer 2025027339 13 2,200 - 3,500 lbs. 1.9800" 125102 L44610 L44649 2025027362 15 5,200 lbs. 2.3280" 124292 LM67010 LM67048 2025027358 6 6,000 lbs. 2.4409" 126996 15245 15123 2025027359 6 7,000 lbs. 2.7170" 127012 14276 14125A 2025027345 5 8,000 lbs. 2.6875" 168687 02420 02475 2025027340 5 10,000 lbs. 3.2650" 124287 25520 25580 2025027364 8 12,000 - 16,000 lbs. 3.8437" 293381 28622 28682 Inner 2025027339 13 2,200 lbs. 1.9800" 125102 L44610 L44649 2025027337 8 3,500 lbs. 2.3612" 124296 L68111 L68149 2025027340 5 5,200 - 8,000 lbs. 3.2650" 124287 25520 25580 2025027357 7 10,000 lbs. 3.8125" 183463 382A 387A 2025027363 5 12,000 - 16,000 lbs. 4.4375" 293379 3920 3984 RACES • Provides protective barrier between the axle hub and the outside elements • Hassle-free grease application • Double-lip design keeps water out for long-lasting performance • Durable construction withstands tough conditions and reduces maintenance frequency Retail Clamshell # Sleeve # Sleeve Qty Axle Capacity Spindle Shaft Diameter Hub Bore Diameter Grease Seals -- 2025047575 30 1,250 lbs. 1.250" 1.983" 2023134653 2025047573 30 2,200 lbs. 1.500" 1.983" 2023134654 2025047571 20 3,500 - 4,400 lbs. 1.719" 2.561" 2023134655 2025047572 30 5,200 - 8,000 lbs. 2.250" 3.371" 2023134019 2025027330 10 10,000 lbs. 2.875" 3.875" 2023134020 2025027332 10 12,000 - 16,000 lbs. 3.125" 4.500" Unitized Oil Seals 2023134018 2025027331 20 5,200 - 8,000 lbs. 2.250" 3.371" 2023134019 2025027330 10 10,000 lbs. 2.875" 3.875" 2023134020 2025027332 10 12,000 - 16,000 lbs. 3.125" 4.500" GREASE SEALS & UNITIZED OIL SEALS (M6V) 2023134018 2023134654 Universally compatible with Dexter
13 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts PREMIUM THREADED DUST CAPS • Magnetic vent plug attracts damaging metal particles • Helps identify problems before they become critical • Clear lens allows for visual inspection of oil level (oil caps only) • Easy-to-access side port lets you fill or drain lubricant without removing the cap (oil caps only) • Powder-coated aluminum construction provides durability and resistance to corrosion STANDARD PRESS-IN DUST CAPS • Keeps dust and debris out, maintaining hub performance • Zinc-plated steel construction • For use with grease lubricated systems • Easy, drive-in installation RUBBER PLUG FOR PRESS-IN DUST CAPS • Seals off dust cap from dirt and debris • Dust caps sold separately Cap diameter A Brown Box # Axle Capacity Cap Diam. (A) Lube Material Includes Threaded Grease Caps 85373929 8,000 lbs. 2-7/8" Non-lubed Die-cast aluminum, smoked lens Rubber plug, O-ring 85373829 10,000 - 16,000 lbs. 4" Non-lubed Die-cast aluminum, smoked lens Rubber plug, O-ring Threaded Oil Caps 85373928 8,000 lbs. 2-7/8" Oil Die-cast aluminum, clear lens Rubber plug, O-ring 85373828 10,000 - 16,000 lbs. 4" Oil Die-cast aluminum, clear lens Rubber plug, O-ring 85373928 85373929 85373828 85373829 Retail Clamshell # 10-Pack # Axle Capacity Bore Size 2023134012 693722 2,200 - 8,000 lbs. Universal Retail Clamshell # 10-Pack # Axle Capacity Cap Diameter (A) Lube Material 2023134658 693794 2,200 - 4,400 lbs. 1.99" Non-lubed Zinc-plated steel 2023134661* 693824 2,200 - 4,400 lbs. 1.99" Super lube Zinc-plated steel 2023134659 693795 5,200 - 6,000 lbs. 2.45" Non-lubed Zinc-plated steel 2023134662* 693749 5,200 - 6,000 lbs. 2.45" Super lube Zinc-plated steel 2023134660 2023134661 7,000 - 8,000 lbs. 2.72" Non-lubed Zinc-plated steel 2023134011* 693748 7,000 - 8,000 lbs. 2.72" Super lube Zinc-plated steel * Includes rubber plugs 2023134658 2023134661 Shields bearings, grease, and other inner hub components from dust and contaminants Grease cap with rubber plug allows easy access to grease zerk in axle spindle 2023134012 (M6V)
14 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts Retail Clamshell # Clamshell Quantity 10-Pack # Diameter Shoulder Length Thread Size Suggested Nut # 2023134013 6 2025027413 0.617" knurl 2" 1/2"-20 122076 2025047362 6 2025027416 0.545" knurl 2" 1/2"-20 122076 2023134014 4 2025027412 0.617" knurl 2-5/16" 9/16"-18 134581 2024055282 4 2025027414 0.689" knurl 2-5/16" 9/16"-18 134581 2024055283 4 2025027415 0.689" knurl 2-3/4" 5/8"-18 176321 or 723971 2024055284 4 2025027411 0.689" knurl 3-7/16" 5/8"-18 176321 or 723971 2024055285 4 2025027417 1.007" knurl 4-13/16" M22-1.5 352303 WHEEL STUDS Retail Clam # Qty 10-Pack # Type Thread Size 2024039634 8 2025027782 Hex flange 5/8"-18 2024039632 6 2025027777 60° cone wheel 1/2"-20 2024039633 8 2025027778 60° cone wheel 9/16"-18 2024039635 8 2025027784 Swiveling flange 5/8"-18 2025047365 8 2025027785 Swiveling flange M22-1.5 LUG NUTS 2024055283 2024039632 2024039633 2024039635 2025047365 2024055285 2024055284 2024055282 2025047362 2024039634 2023134013 2023134014 (M6V)
15 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) HANGERS • Welded to the chassis to allow the mounting of axles and axle components • Constructed from 1/4" thick steel for a reliable connection Part # Axle Capacity Location To Hole (A) Length (B) Width (C) Hole Size (D) 127784 2,200 - 8,000 lbs. Front 3-9/16" 4-5/16" 2-3/16" 9/16" 127783 2,200 - 8,000 lbs. Rear 4" 6" 2-1/4" 5/16" 127782 2,200 - 8,000 lbs. Center 3-5/16" 4-1/2" 3-1/8" 7/8" 182242 10,000 lbs. Front 5-1/2" 8" 2-3/4" 3/4" 182245 10,000 lbs. Rear 6-1/8" 8" 2-3/4" -- 184079 10,000 lbs. Center 1-7/8" 3-1/4" 4-1/8" 1" 298462 12,000 - 16,000 lbs. Front 6-1/4" 7-1/2" 3-1/8" 1" 298458 12,000 - 16,000 lbs. Center 4-1/8" 5-5/8" 3-7/8" 1-1/8" 298553 12,000 - 16,000 lbs. Rear 6-5/8" 8-1/2" 3-1/8" 1/2" Part # Axle Capacity To Hole (A) Length (B) Width (C) Hole Size (D) 106181 2,200 - 8,000 lbs. 1-1/4" 1-15/16" 2" 9/16" 106182 2,200 - 8,000 lbs. 2-1/4" 2-15/16" 2" 9/16" 106183 2,200 - 8,000 lbs. 3-1/4" 3-1/16" 2" 9/16" 106185 2,200 - 8,000 lbs. 4-1/4" 4-15/16" 2" 9/16" 106184 2,200 - 8,000 lbs. 5" 5-5/8" 2" 9/16" 102906 2,200 - 8,000 lbs. 3" (A) / 5" (A1) 5" 2" 9/16" 106185 106181 106184 102906 184079 106182 106183 127784 298462 298458 298553 127783 127782 182242 182245 A D B C A A1 D Slipper leaf spring hangers Double-eye leaf spring hangers
16 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) DOUBLE-EYE LEAF SPRINGS Arch C A F C A Arch F SLIPPER LEAF SPRINGS Universally compatible with Dexter Universally compatible with Dexter Brown Box # Spring Capacity Industry Number* # of Leaves Spring Width Eye-to-End Length (A) Arch Height Unloaded (C) Arch Height Loaded (C) Eye Diam. (F) 132819 1,000 lbs. 72-02 2 1-3/4" 27" 4-3/16" 3-1/8" 9/16" 230281 1,250 lbs. BT25-12 4 1-3/4" 25" 3-1/2" 2-1/4" 9/16" 157739 1,750 lbs. BT25-22 3 1-3/4" 25" 3-1/2" 2-1/2" 9/16" 136527 2,000 lbs. 72-30 4 2" 26-7/8" 3" 2" 9/16" 125250 2,500 lbs. 72-31 4 2" 26-7/8" 3-1/16" 2" 9/16" 710493 3,500 lbs. 72-32 5 2" 26-7/8" 3-3/16" 2" 9/16" 342781 3,500 lbs. E5226 5 2" 26-1/2" 3-1/4" 2-1/2" 9/16" 797547 3,500 lbs. HW5116 6 2" 26-1/2" 3-1/4" 2" 9/16" 710494 4,000 lbs. 72-33 7 2" 26-7/8" 3-3/16" 2" 9/16" 334744 4,000 lbs. E5115 6 2" 29-1/2" 3-1/2" 2-1/2" 9/16" 796558 4,000 lbs. E5226/7 7 2" 26-1/2" 3-1/4" 2" 9/16" 176326 5,000 lbs. 72-80 5 2-1/2" 30-1/2" 4" 2-11/16" 3/4" 296155 6,000 lbs. 72-44 6 3" 30-1/2" 4" 2-3/4" 1" 353498 8,000 lbs. 72-46 6 3" 30-1/2" 4" 2-3/4" 1" 771492 11,200 lbs. 354-00 3 3" 43-3/4" 6-1/4" 5-1/4" N/A * Note: Industry number is for reference only. Do not use this number to order your parts Brown Box # Spring Capacity Industry Number* # of Leaves Spring Width Unloaded Eye-toEye Length (A) Loaded Length Arch Height Unloaded (C) Arch Height Loaded (C) Eye Diam. (F) 127094 1,000 lbs. 72-17 3 1-3/4" 20-3/8" 21" 2-7/8" 2-1/8" 9/16" 127103 1,250 lbs. 72-06 3 1-3/4" 23-1/8" 24" 3-1/2" 2-1/2" 9/16" 125215 1,750 lbs. 72-09 3 1-3/4" 23-3/16" 24" 3-1/2" 2-1/2" 9/16" 125799 2,000 lbs. 72-18 3 1-3/4" 23-1/8" 24" 3-1/2" 2-1/2" 9/16" 125797 2,000 lbs. 72-24 3 1-3/4" 25-1/4" 26" 3" 1-3/4" 9/16" 699453 2,000 lbs AWS-4 4 1-3/4” 26" 27” 4-1/4” 3” 9/16” 125269 1,400 lbs. 72-13 4 1-3/4" 20-1/2" 21" 3-1/2" 2-3/8" 9/16" 124903 1,750 lbs. 72-42 4 1-3/4" 25-1/4" 26" 3" 1-1/2" 9/16" 702096 3,000 lbs. 72-26 4 1-3/4" 25-1/4" 26" 3-1/8" 1-3/4" 9/16" 129745 2,200 lbs. 72-78 4 1-3/4" 25-1/4" 26" 3-1/8" 2" 9/16" 133982 2,500 lbs. 72-20 4 1-3/4" 23-1/8" 24" 3-1/2" 2-1/2" 9/16" 702095 2,600 lbs. 72-97 4 1-3/4" 25-1/4" 26" 3-1/8" 1-3/4" 9/16" 334743 3,000 lbs SW-5 5 1-3/4" 25-1/4" 26" 3-1/8" 1-3/4" 9/16" 679372 3,500 lbs. 72-98 6 1-3/4" 24-7/8" 26" 3-1/4" 1-3/4" 9/16" 2021095282 4,000 lbs. 72-100 7 1-3/4" 24-7/8" 26" 3-1/4" 1-3/4" 9/16" * Note: Industry number is for reference only. Do not use this number to order your parts
17 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts Part # Description Qty 182257 Equalizer 2 184138 Bolt - 1" - 8 x 6" 2 184137 Bolt - 3/4"-10 x 4-1/2" 2 178715 Nut - 1"-8 2 119094 Nut - 3/4" - 10 4 • Compatible with 10,000-lb. axles • Use with 2-1/2" wide slipper springs • Axle spacing: 42-1/4" Tandem Axle Kit - #184173 Part # Description Qty 127771 Equalizer 2 126782 Bolt - 9/16"-18 x 3-1/2" 2 127846 Bolt - 7/8"-9 x 4-5/8" 2 127828 Bolt - 5/16"-18 x 3-1/4" 4 125801 Nut - 9/16"-18 2 127802 Nut - 7/8"-9 2 127799 Nut - 5/16"-18 4 • Compatible with 3,500 to 8,000-lb. axles • Use with 2" wide slipper springs • Axle spacing: 33-1/2" • Industry standard #: EQ-13-4 Tandem Axle Kit - #128877 Part # Description Qty 182269 Equalizer 6 184138 Bolt - 1"-8 x 6" 2 184137 Bolt - 3/4"-10 x 4-1/2" 4 178715 Nut - 1"-8 2 119094 Nut - 3/4"-10 4 • Compatible with 10,000-lb. axles • Use with 2-1/2" wide slipper springs • Axle spacing: 48-1/2" Tandem Axle Kit - #184175 Part # Description Qty 165270 Equalizer 2 126782 Bolt - 9/16"-18 x 3-1/2" 4 127846 Bolt - 7/8"-9 x 4-5/8" 2 127828 Bolt - 5/16"-18 x 3-1/4" 4 125801 Nut - 9/16"-18 4 127802 Nut - 7/8"-9 2 127799 Nut - 5/16"-18 4 • Compatible with 3,500 to 8,000-lb. axles • Use with 2" wide slipper springs • Axle spacing: 36" • Industry standard #: EQ-13-44 Tandem Axle Kit - #165268 SLIPPER SUSPENSION KITS • Complete kit includes equalizers and attaching hardware to mount your axle to the chassis All kit component SKUs are for reference only (M6V)
18 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts SLIPPER SUSPENSION KITS Part # Description Qty 127771 Equalizer 4 126782 Bolt - 9/16"- 8 x 3-1/2" 6 127846 Bolt - 7/8"-9 x 4-11/16" 4 127828 Bolt - 5/16"-18 x 3-1/4" 6 125801 Nut - 9/16"-18 6 127802 Nut - 7/8"-9 4 127799 Nut - 5/16"-18 6 • Compatible with 3,500 to 8,000-lb. axles • Use with 2" wide slipper springs • Axle spacing: 33-1/2" • Industry standard #: EQ-13-4 Triple Axle Kit - #137383 Part # Description Qty 165270 Equalizer 4 126782 Bolt - 9/16"-18 x 3-1/2" 6 127846 Bolt - 7/8" 9 x 4-5/8" 4 127828 Bolt - 5/16"-18 x 3-1/4" 6 125801 Nut - 9/16"-18 6 127802 Nut - 7/8"-9 4 127799 Nut - 5/16"-18 6 • Compatible with 3,500 to 8,000-lb. axles • Use with 2" wide slipper springs • Axle spacing: 36" • Industry standard #: EQ-13-44 Triple Axle Kit - #169381 Part # Description Qty 299015 Equalizer 2 301404 Bolt - 1-1/8"-7 x 6" 2 301405 Bolt - 1"-8 x 5-1/2" 4 301406 Bolt - 1/2"-20 x 4-1/2" 4 301408 Nut - 1-1/8"-7 2 301409 Nut - 1"-8 4 301410 Hex flange nut - 7/16"-20 4 • Compatible with 12,000 - 16,000-lb. axles • Use with 3" wide slipper springs • Axle spacing: 42-1/4" Tandem Axle Kit - #302934 Part # Description Qty 299017 Equalizer 2 301404 Bolt - 1-1/8"-7 x 6" 2 301405 Bolt - 1"-8 x 5-1/2" 4 301406 Bolt - 1/2"-20 x 4-1/2" 4 301408 Nut - 1-1/8"-7 2 301409 Nut - 1"-8 4 301410 Hex flange nut - 7/16"-20 4 • Compatible with 12,000 - 16,000-lb. axles • Use with 3" wide slipper springs • Axle spacing: 48-1/2" Tandem Axle Kit - #302964 • Complete kit includes equalizers and attaching hardware to mount your axle to the chassis All kit component SKUs are for reference only (M6V)
19 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts SLIPPER SUSPENSION KITS Part # Description Qty 299017 Equalizer 4 301404 Bolt - 1-1/8"-7 x 6" 4 301405 Bolt - 1"-8 x 5-1/2" 6 301406 Bolt - 1/2"-20 x 4-1/2" 6 301408 Nut - 1-1/8"-7 4 301409 Nut - 1"-8 6 301410 Hex flange nut - 7/16"-20 6 • Compatible with 12,000 - 16,000-lb. axles • Use with 3" wide slipper springs • Axle spacing: 48-1/2" Triple Axle Kit- #321436 Part # Description Qty 299015 Equalizer 4 301404 Bolt - 1-1/8"-7 x 6" 4 301405 Bolt - 1"-8 x 5-1/2" 6 301406 Bolt - 1/2"-20 x 4-1/2" 6 301408 Nut - 1-1/8"-7 4 301409 Nut - 1"-8 6 301410 Hex flange nut - 7/16"-20 6 • Compatible with 12,000 - 16,000-lb. axles • Use with 3" wide slipper springs • Axle spacing: 42-1/4" Triple Axle Kit - #321435 Part # Description Qty 182257 Equalizer 4 184138 Bolt - 1" - 8 x 6" 4 184137 Bolt - 3/4"-10 x 4-1/2" 6 178715 Nut - 1"-8 4 119094 Nut - 3/4" - 10 6 • Compatible with 10,000-lb. axles • Use with 2-1/2" wide slipper springs • Axle spacing: 42-1/4" Triple Axle Kit - #184174 Part # Description Qty 182269 Equalizer 4 184138 Bolt - 1"-8 x 6" 4 184137 Bolt - 3/4"-10 x 4-1/2" 6 178715 Nut - 1"-8 4 119094 Nut - 3/4"-10 6 • Compatible with 10,000-lb. axles • Use with 2-1/2" wide slipper springs • Axle spacing: 48-1/2" Triple Axle Kit - #184176 • Complete kit includes equalizers and attaching hardware to mount your axle to the chassis All kit component SKUs are for reference only (M6V)
20 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts DOUBLE-EYE SUSPENSION KITS Part # Description Qty 126741 Equalizer assembly 2 125675 Shackle link assembly - 2-1/4" 4 122487 Shackle link - 2-1/4" 4 122102 Shoulder bolt - 9/16" x 2-5/16" 6 122103 Flange nut - 7/16"-20 14 • Compatible with 2,200 - 8,000-lb. axles • Use with 1-3/4" wide double-eye springs • Axle spacing: 33" • Industry standard #: EQ-310 Tandem Axle Kit- #121098 Part # Description Qty 126460 Equalizer assembly 2 125675 Shackle link assembly 4 122102 Bolt - .438 - 20 x 2-7/8" 6 122487 Shackle link - 2-1/4" 4 122103 Nut - 7/16 - 20 14 • Compatible with 2,200 - 8,000-lb. axles • Use with 1-3/4" wide double-eye springs • Axle spacing: 33" • Industry standard #: EQ-104 Tandem Axle Kit - #121097 Part # Description Qty 133485 Shackle assembly 2 122102 Shoulder bolt - 9/16" x 2-5/16" 2 133207 Shackle link - 3-1/8" 2 122103 Nut - 7/16"-20 6 • Compatible with 2,200 - 8,000-lb. axles • Use with 1-3/4" wide double-eye springs Single Axle Kit - #121101 Part # Description Qty 156766 Shackle link assembly 4 126238 Bolt - 9/16" x 2-5/16" 6 716205 Shackle links 4 122103 Hex flange nut - 7/16"-20 14 • Compatible with 2,200 - 8,000-lb. axles • Use with 1-3/4" wide double-eye springs • Axle spacing: 33" or 35" Tandem Axle Kit - #156767 • Complete kit includes equalizers and attaching hardware to mount your axle to the chassis All kit component SKUs are for reference only (M6V)
21 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) Part # Description Qty 122106 Equalizer assembly 2 181823 Equalizer 2 125675 Shackle link assembly - 2-1/4" 6 122102 Shoulder bolt - 9/16" x 2-5/16" 10 122487 Shackle link - 2-1/4" 6 122103 Hex flange nut - 7/16"-20 22 • Compatible with 2,200 - 8,000-lb. axles • Use with 1-3/4" wide double-eye springs • Axle spacing: 35" • Industry standard #: EQ-1 & 13-126 Triple Kit - #132698 Part # Description Qty 126277 Equalizer 2 126460 Equalizer assembly 2 125675 Shackle link assembly 6 122102 Shoulder bolt - 9/16" x 2-5/16" 10 122487 Shackle link - 2-1/4" 6 122103 Hex flange nut - 7/16"-20 22 • Compatible with 2,200 - 8,000-lb. axles • Use with 1-3/4" wide double-eye springs • Axle spacing: 33" • Industry standard #: EQ-104 & 105 Triple Kit - #121100 Part # Description Qty 122106 Equalizer assembly 2 125675 Shackle link assembly - 2-1/4" 4 122102 Shoulder bolt - 9/16" x 2-5/16" 6 122487 Shackle link - 2-1/4" 4 122103 Hex flange nut - 7/16"-20 14 • Compatible with 2,200 - 8,000-lb. axles • Use with 1-3/4" wide double-eye springs • Axle spacing: 35" • Industry standard #: EQ-E1 Tandem Kit - #121099 DOUBLE-EYE SUSPENSION KITS • Complete kit includes equalizers and attaching hardware to mount your axle to the chassis All kit component SKUs are for reference only
22 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) EQUALIZERS How to measure different equalizer styles • Connects the springs on tandem or triple-axle trailers • Transfers load and impact from one axle to another by permitting movement between the axles • Pre-installed bushings maintain a well-functioning system and ensure proper sizing for suspension bolts • Includes one equalizer in a durable brown box Brown Box # Industry Number* Number of Axles Spring Width Axle Spacing Type A (Width) B (Height) 1277711 EQ-1304 2 / 3 2" 33-1/2" 3 5-1/8" 4-5/8" 182257 -- 2 / 3 2-1/2" 42-1/4" 3 6-7/8" 6-11/16" 182269 -- 2 / 3 2-1/2" 48-1/2" 3 9-9/16" 9-9/16" 299015 -- 2 / 3 3" 42-1/4" 3 7" 7-1/8" 299017 -- 2 / 3 3" 48-1/2" 3 10-3/4" 10-1/4" * Note: Industry number is for reference only. Do not use this number to order your parts Brown Box # Industry Number* Number of Axles Spring Width Axle Spacing Type A (Width) B (Height) 126460 EQ-104 2 1-3/4" 33" 1 5-3/4" 2" 122106 EQ-E1 2 1-3/4" 35" 1 7-3/4" 2-7/8" 126741 EQ-310 2 1-3/4" 33" 1 6-1/16" 4" 126277 EQ-105 3 1-3/4" 33" 2 6-3/4" 2" 181823 EQ-126 3 1-3/4" 35" 2 8-11/16" 2-1/2" * Note: Industry number is for reference only. Do not use this number to order your parts Type 2 126277 A B Type 3 1277711 A B Type 1 126460 A B 126460 1277711 122106 182257 126741 182269 126277 299015 181823 299017 Slipper leaf spring equalizers Double-eye leaf spring equalizers
23 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) SHACKLE LINK ASSEMBLIES SHACKLE LINKS • Connects suspension springs and axle hangers • Typically used with greaseable wet bolts • Zinc-plated construction • Designed for 1-3/4" wide double-eye spring suspension kits • Connects suspension springs to the rear hanger or equalizer on your trailer • Typically used with greaseable wet bolts Part # Shackle Thickness Center-to-Center Suggested Nut # 125675 0.224" 2-1/4" 122103 133485 0.224" 3-1/8" 122103 126205 1/2" 2-1/4" 122103 156766 1/2" 3-1/8" 122103 Retail Clamshell 4-Pack # 10-Pack # Shackle Thickness Center-to-Center 2024120104 2025027382 0.224" 2-1/4" 2024120105 2025027383 0.224" 3-1/8" 2024120108 2025027384 1/2" 2-1/4" 2024120109 2025027385 1/2" 3-1/8" 2024120104 125675 SUSPENSION BOLTS SUSPENSION NUTS • Designed for 1-3/4" widedouble-eye spring suspension kits • Connects suspension springs and axlehangers in conjunction with shackle links • Grease zerk allows for easy lubrication to keep moving parts functioning properly (select SKUs) • Zinc-plated construction for corrosion resistance 2024120106 2024120107 Retail 4-pack # 10-Pack # Type Diameter Shoulder Length Thread size Suggested Nut -- 2025047556 Hex bolt 5/16” 3-1/4" 5/16"-18 2025047554 -- 2025047565 Hex bolt 1/2" 4-1/2” 1/2"-20 2025047566 2024120106 2025027751 Shoulder bolt 9/16" 2-5/16" 7/16"-20 2025027783 2025047366 2025027731 Shoulder bolt 9/16" 2-13/16" 7/16"-20 2025027783 2024120107 2025027733 Wet bolt 9/16" 2-5/16" 7/16"-20 2025027783 2024120110 2025027732 Wet bolt 9/16" 2-13/16" 7/16"-20 2025027783 -- 2025047553 Hex bolt 9/16” 3-1/2" 9/16"-18 2025047552 -- 2025047559 Hex bolt 3/4" 4-1/2" 3/4"-10 2025047551 -- 2025047557 Wet bolt 7/8” 4-3/4" 7/8"-9 2025047555 -- 2025047560 Hex bolt 1” 6" 1"-8 2025047558 -- 2025047564 Hex bolt 1” 5-1/2" 1"-8 2025027796 -- 2025047563 Hex bolt 1-1/8” 6" 1-1/8"-7 2025027801 2025027783 10-Pack # Type Thread size 2025047554 Hex nut 5/16"-18 2025027783 Hex flange nut 7/16"-20 2025047566 Hex flange nut 1/2"-20 2025047552 Hex nut 9/16"-18 2025047551 Hex lock nut 3/4"-10 2025047555 Hex lock nut 7/8"-9 2025047558 Hex lock nut 1"-8 2025027796 Hex nut 1"-8 2025027801 Hex nut 1-1/8"-7
24 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts SHACKLE LINKS Retail Clamshell 4-Pack # Shackle Thickness Center-to-Center 2024120104 0.224" 2-1/4" 2024120105 0.224" 3-1/8" 2024120108 1/2" 2-1/4" 2024120109 1/2" 3-1/8" 2024120104 2024120109 BUSHINGS Retail Clam # Qty Material Inside Diam. Length 2025009017 4 Bronze 9/16" 1-3/4" 2025009018 8 Bronze 9/16" 1-3/4" 2024110549 4 Nylon 9/16" 1-3/4" 2024110550 8 Nylon 9/16" 1-3/4" 2025009017 2024110550 2024118832 U-BOLT MOUNTING KITS Retail Box # Axle Capacity Length Slipper Spring Width Double-Eye Spring Width 2024118832 8,000 lbs. 7-1/4" 2" 1-3/4" SUSPENSION BOLT & NUT KITS Retail Clamshell 4-Pack # Type Diameter Shoulder Length 2024120106 Shoulder bolt 9/16" 2-5/16" 2025047366 Shoulder bolt 9/16" 2-13/16" 2024120107 Wet bolt 9/16" 2-5/16" 2024120110 Wet bolt 9/16" 2-13/16" 2024120106 2024120107 U-BOLT & NUT KITS Retail # Axle Capacity Fits Axle Tube Size Length Clamshell 2024117444 2,200 lbs. 1-3/4" 4-3/8" 2024117446 3,500 lbs. 2-3/8" 5-1/8" 2024117447 4,400 lbs. 3" 6-1/2" Retail Box 2024117449 8,000 lbs. 3" 7-1/4" 2024117450 10,000 lbs. 4" 8-3/4" 2024117451 10,000 - 16,000 lbs. 5" 10" 2024117444 2024117451 (M6V)
25 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts (M6V) 297426 297427 297429 2024118832 U-BOLT MOUNTING KITS • Zinc-plated U-bolts and nuts with black powder-coated tie plates • Durable steel construction for long-lasting performance • Features fine threads for superior holding strength • Includes four U-bolts, two tie-plates, and eight nuts Part # Axle Capacity Fits Axle Tube Size Length Thread Size Slipper Spring Width Double-Eye Spring Width 297426 2,200 lbs. 1-3/4" 4-3/8" 3/8"-24 2" 1-3/4" 297427 3,500 lbs. 2-3/8" 5-1/8" 1/2"-20 2" 1-3/4" 297429 4,400 lbs. 3" 6-1/2" 1/2"-20 2" 1-3/4" 2024118832 8,000 lbs. 3" 7-1/4" 9/16"-18 2" 1-3/4" U-BOLT & NUT KITS • Zinc-plated finish on U-bolts resists rust and corrosion • Durable steel construction for long-lasting performance • Features fine threads for superior holding strength • Includes two U-bolts and four nuts Retail # Axle Capacity Fits Axle Tube Size Length Thread Size 2024117444 2,200 lbs. 1-3/4" 4-3/8" 3/8"-24 2024117446 3,500 lbs. 2-3/8" 5-1/8" 1/2"-20 2024117447 4,400 lbs. 3" 6-1/2" 1/2"-20 2024117449 8,000 lbs. 3" 7-1/4" 9/16"-18 2024117450 10,000 lbs. 4" 8-3/4" 5/8"-11 2024117451 10,000 - 16,000 lbs. 5" 10" 5/8"-11 2024117447 2024117449 2024117451 2024117450 2024117446 2024117444
26 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components (A1W) Brake Assemblies and Axle Parts Axle Leaf Springs Shackle Link Hangers 014125269 0141261714 Part No. Description 014127094 Axle Leaf Springs 1,000 lbs., 3 leaves, 20-3/8” +/- 1/8” eye to eye length, 0.786” +/- .015” stacked leaf thickness, 2.12” loaded arch height, 1.72”-1.85” stack leaf width 014127103 Axle Leaf Springs 1,250 lbs., 3 leaves, 23-1/8” +/- 1/8” eye to eye length, 0.937” +/- .015” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” stack leaf width 014125269 Axle Leaf Springs 1,400 lbs., 4 leaves, 20-1/2” +/- 1/8” eye to eye length, 1.106” +/- .020” stacked leaf thickness, 2.38” loaded arch height, 1.72”-1.85” stack leaf width 014125215 Axle Leaf Springs 1,750 lbs., 3 leaves, 23-1/8” +/- 1/8” eye to eye length, 1.080” +/- .015” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” Stack leaf width 014124903 Axle Leaf Springs 1,750 lbs., 4 leaves, 25-1/4” +/- 1/8” eye to eye length, 1.272” +/- .020” stacked leaf thickness, 1.50” loaded arch height, 1.72”-1.85” stack leaf width 014125799 Axle Leaf Springs 2,000 lbs., 4 leaves, 23-1/8” +/- 1/8” eye to eye length, 1.366” +/- .020” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” stack leaf width 014125797 Axle Leaf Springs 2,000 lbs., 3 leaves, 25-1/4” +/- 1/8” eye to eye length, 1.162” +/- .017” stacked leaf thickness, 1.75” loaded arch height, 1.72”-1.85” stack leaf width 014133982 Axle Leaf Springs 2,500 lbs., 4 leaves, 23-1/8” +/- 1/8” eye to eye length, 1.440” +/- .020” stacked leaf thickness, 2.50” loaded arch height, 1.72”-1.85” stack leaf width 014122111 Axle Leaf Springs 3,000 lbs., 4 Or 5 leaves, 25-1/4” +/- 1/8” eye to eye length, 1.563” +/- .020” stacked leaf thickness, 1.75” loaded arch height, 1.72”-1.85” stack leaf width 014122113 Axle Leaf Springs 3,500 lbs., 6 leaves, 24-7/8” +/- 1/8” eye to eye length, 2.049” +/- .030” stacked leaf thickness, 1.75” loaded arch height, 1.72”-1.85” stack leaf width 0141261714 4 pack spring bushing - bronze 014126282 Spring bushing - nylon 014125250 Slipper Spring 2,500 lbs., 4 leaves, eye to eye 26.5” 014125203 Slipper Spring 3,500 lbs., 5 leaves, eye to eye 26.5” Measure center of hole to center of hole. Order second link plate and nuts separately. 014122487 014125675 014133485 014122102 014106182 014106184 014102906 A C B D Part No. Description 014122487 2-1/4” Shackle Link with yellow zinc 014125675 2-1/4” Shackle Link / bolt assembly 014133207 3-1/8” Shackle Link, silver zinc 014133485 3-1/8” Shackle Link / bolt assembly 014122103 7/16” x 20 Flanged Hex Lock Nut, zinc 014122102 2.32 x 9/16” with 7/16” - 20 threaded shoulder bolt, black phosphorus coated Part No. Description A B C D 014106183 3.25 Axle Hanger 3.95” 2” 3” 9/16” 014106182 2.25” Axle Hanger 2.95” 2” 3” 9/16” 014106181 1.25” Axle Hanger 1.95” 2” 3” 9/16” 014106185 4.25” Axle Hanger 4.82” 2” 3” 9/16” 014106184 5” Axle Hanger 5.62” 2” 3” 9/16” 014102906 Boot Hanger, 3” and 5” 5.775” 2” 5” 9/16”
27 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components (A1W) Brake Assemblies and Axle Parts Spindles Washers And Nuts Tie Plates, Shock Kits, And U-Bolts Equalizers Part No. Description 014142161 2,200 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 1.75” 014142162 2,200 lbs. Sprung Axle Spindle - Straight, No Flg, Lube, 1.75” 014123383 2,800 - 3,500 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 2.38” 014134563 2,800 - 3,500 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 3” 014123384 2,800 - 3,500 lbs. Sprung Axle Spindle - Drop, Flg, Lube, 2.38” 014140695 2,800 - 3,500 lbs. Sprung Axle Spindle - Drop, Flg, Lube, 3” 014122455 4,000 - 7,000 lbs. Sprung Axle Spindle - Straight, Flg, Lube, 3” 014122456 4,000 - 7,000 lbs. Sprung Axle Spindle - Drop, Flg, Lube, 3” 014122081 6 Slot Spindle Nut, 1” - 14 UNS 014119335 2pk Spindle Nuts and Washers, 1” D-Flat and Tang Washers, 6 Slot Nut Part No. A B C D E F H 014142161 1.31" 1.63" 6.7" 1.5" 1.062" 1.062" 1.75" 014142162 1.31" NA 5.61" 1.5" 1.062" 1.062" 1.75" 014123383 2" 2.26" 6.23" 1.72" 1.376" 1.062" 2.44" 014134563 2.55" 2.26" 6.23" 1.72" 1.376" 1.062" 3" 014123384 2" 2.26" 8.13" 1.72" 1.376" 1.062" 2.44" 014140695 2.55" 2.26" 8.13" 1.72" 1.376" 1.062" 3" 014122455 2.46" 2.75" 8.13" 2.25" 1.749" 1.249" 3" 014122456 2.46" 2.75" 9.89" 2.25" 1.749" 1.249" 3" Part No. Description 014139737 U-Bolt 3/8” - 24 x 4.00” for 1.75” Tube, YZ 014122073 U-Bolt 1/2” - 20 x 5.10” for 2.38” Tube, YZ 014122070 U-Bolt 1/2” - 20 x 6.50” for 3.00” Tube, YZ 014132049 U-Bolt 1/2” - 20 x 7.25” for 3.00” Tube, YZ 014139874 1.75” Tie Down Plate uses 3/8” U-Bolts 014133766 2.375” Tie Down Plate for 2” Spring 014122226 3” Zinc Tie Down Plate(2” Slipper Spring) Zinc 014146677 Over/Under Conversion Kit for 23⁄8” Tube 014162753 Over/Under Conversion Kit for 3” Tube 014156018 Shock Kit w/Tie Plates For 23⁄8” and 3” Tube 014122108 Shock Kit with Hardware 014119215 014119214 014119216 014126741 014122106 014156018 014126277 Part No. Description 014119215 1” D-Flat Spindle Washer 014119214 1” Round Spindle Washer 014119216 Tang Washer 12207510 10pk Cotter Pin 1/8” x 1.75” 014122103 7/16” x 20 Flanged Hex Lock Nut, Zinc 014122081 6 Slot Spindle Nut, 1” - 14 UNS 014122079 1/2” x 20 Zinc Coated Flange Nut 014122077 3/8” - 24 Self-Locking Keps Nut Part No. Description 014122085 7/16” - 20 Hex Nut Zinc Plated 014122076 1/2” - 20, 60-Degree Cone Wheel Nut 014127146 1/2” - 20 UNF 2B Cap Nut 014134581 9/16” - 18, 60-Degree Wheel Nut 014119335 2pk Spindle Nuts and Washers, 1” D-Flat and Tang Washers, 6-Slot Nut Part No. Description A B C D 014122106 EQ-E1 Assembly 7.75” 9/16” 9/16” 2.88” 014126277 EQ-105 Assembly 6.75” 9/16” 9/16” 2” 014126460 EQ-104 Assembly 5.75” 9/16” 9/16” 2” 014126741 EQ-310 Assembly 6.13” 9/16” 9/16” 4” 014127467 EQ-356 Assembly 6.13” 9/16” 9/16” 2.50” A B C D E F H C A D B E F H C A D B All Equalizers include nylon bushings Shock and mounting hardware to install shock to axle’s suspension. Axle must have appropriate tie plate and frame mount to bolt shock to. Direct OEM replacement for many popular trailers. Dimensions: Overall 18.00” extended, 15.81” nominal, 13.62” compressed, Body 7.50”: compressed +/-.12” (4.50” travel), 12.00” extended +/-.12” (3.38” dead length). 014142161 014122455 014134563 014122108 014162753 014122070
28 See manufacturer’s catalog for more applications. Specifications are subject to change without notice. Axles & Components Brake Assemblies and Axle Parts Part No. Description 014121101 Single Axle A/P Kit with 3-1/8" Link 014121097 15" Tandem A/P Kit for 33" Axle spacing EQ-104 014121098 15" Tandem A/P Kit for 33" Axle spacing 4" tall EQ-310 014121099 16" Tandem A/P Kit for 35" Axle spacing EQ-E1 014121100 Triple A/P Kit for 33" Axle spacing EQ-104 and EQ-105 014128877 Tandem Slipper A/P Kit for 33.5" Axle spacing, with EQ 13-4 014137383 Triple Slipper A/P Kit for 33.5" Axle spacing, with EQ 13-4 014146220 Triple A/P Kit for 35” Axle spacing EQ-104 with wet bolt Part No. Description 014122099 Grease Cap, Non lubed for 2k and 3.5k, DC200, 1.990" 014122067 Grease Cap with rubber plug, Lubed for 2k and 3.5k, DC200L, 1.990" 014122071 Grease Cap, Non Lubed, 5.2k and 6k, DC250, 2.450" 014122064 Grease Cap with rubber plug, Lubed for 5.2k and 6k, 014127300 Grease Cap, Lubed for 7k and 8k, DC275L, 2.71" 014127206 Grease Cap, Non Lubed 7k and 8k, DC275, 2.7520" 0141220655 5pk Universal Rubber LBD Dust Plug Part No. Description 014121803 1⁄2-20 UNF x 1.84”, 0.617 KNURL, Press in Stud 014122290 2.32” x 9⁄16” Shackle Bolt with Nut 014122076 1/2” - 20, 60° Cone Wheel Nut 014127146 1/2” - 20 UNF 2B Cap Nut 014132592 9/16” - 18 Cap Lug Nut 014134581 9/16” - 18 60° Wheel Nut A/P Kits Grease Caps Wheel Studs And Nuts Bearing Kit 014121803 014122290 014121098 014121099 014121100 014128877 014137383 Inner Bearing Grease Seal Outer Bearing 122099 122067 127206 Part No. Description 0141250 Bearing Kit for 1,250 lb. with 1” Spindle (L-44643, L-44643, L-44610, L-44610, Seal and Pin) 0143500 Bearing Kit for 3,500 lb. Axle (L-44649, L-68149, L68111, L-44610, Seal and Pin) 0145200 Bearing Kit for 5,200 lb. Axle, (LM-67048, 25520, LM-67010, 25580, Seal and Pin) 0146000 Bearing Kit for 6,000 lb. Axle, (25580, 15123, 25520, 15245, Seal and Pin) 0147000 Bearing Kit for 7,000 lb. Axle, (25580, 25520, 14125A, 14276, Seal and Pin) 014035122 Bearing Kit for 3,500 lb. Axle (L-44649, L-68149, L68111, L-44610, Lug Nuts, Rubber Plug, Seal and Pin) 014052122 Bearing Kit for 5,200 lb. Axle, (LM-67048, 25520, LM-67010, 25580, Lug Nuts, Rubber Plug, Seal and Pin) 014060122 Bearing Kit for 6,000 lb. Axle, (25580, 15123, 25520, 15245, Lug Nuts, Rubber Plug, Seal and Pin) 014070122 Bearing Kit for 7,000 lb. Axle, (25580, 25520, 14125A, 14276, Lug Nuts, Rubber Plug, Seal and Pin) 0141220872 Double Lip Grease Seal for 2800-3500, 1.72” ID x 2.565” OD - 2pk. 0141395142 Double Lip Grease Seal for 2200, 1.502” ID x 1.987” OD - 2pk. 0141242878 8pk, Inner Cup, 25520, O.D. 3.265 12429213 13pk, Outer Cup, LM-67010, O.D. 2.328 12429613 13pk, Inner Cup, L-68111, O.D. 2.362 12510215 15pk, Outer Cup, L-44610, O.D. 1.98 12699611 11pk, Outer Cup, 15245, O.D. 2.441 12701210 10pk, Outer Cup, 14276, O.D. 2.717 18162810 10pk, Inner/Outer Bearing, L-44643, I.D. 1” 12208910 10pk, Outer Bearing, L-44649, I.D. 1.063 0141220929 9pk, Inner Bearing, L-68149, I.D. 1.378 0141220667 7pk, Inner Bearing, 25580, I.D. 1.75 0141220909 9pk, Outer Bearing, LM-67048, I.D. 1.25 0141220918 8pk, Outer Bearing, 15123, I.D. 1.25 0141270098 8pk, Outer Bearing, 14125A, I.D. 1.25 12208810 10pk, Seal for 5200/6000/7000, I.D. 2.25 12208710 10pk, Seal for 3500 lb., I.D. 1.719 18162110 10pk, Seal 1250 lb. with 1” Spindle, I.D. 1.249 0141242872 2pk, Inner Cup, 25520, O.D. 3.265 0141242922 2pk, Outer Cup, LM-67010, O.D. 2.328 0141242962 2pk, Inner Cup, L-68111, O.D. 2.362 0141251022 2pk, Outer Cup, L-44610, O.D. 1.98 0141269962 2pk, Outer Cup, 15245, O.D. 2.441 0141270122 2pk, Outer Cup, 14276, O.D. 2.717 0141816282 2pk, Inner/Outer Bearing, L-44643, I.D. 1” 0141220892 2pk, Outer Bearing, L-44649, I.D. 1.063 0141220922 2pk, Inner Bearing, L-68149, I.D. 1.378 0141220662 2pk, Inner Bearing, 25580, I.D. 1.75 0141220902 2pk, Outer Bearing, LM-67048, I.D. 1.25 0141220912 2pk, Outer Bearing, 15123, I.D. 1.25 0141270092 2pk,Outer Bearing, 14125A, I.D. 1.25 0141220882 2pk,Seal for 5200/6000/7000, I.D. 2.25 0141220872 2pk,Seal for 3500 lb., I.D. 1.719 0141816212 2pk,Seal 1250 lb. with 1” Spindle, I.D. 1.249 0141300352 3pk, Double Lip Seal, O.D. 3.376 Brake Components (A1W)
